3LN01SS-TL-E Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 3-SSFP
- Description: MOSFET N-CH 30V 150MA SC81
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
3LN01SS-TL-E Specifications:
- MfrPart.: 3LN01SS-TL-E
- Mfr: onsemi
- Description: MOSFET N-CH 30V 150MA SC81
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 150mA (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 1.5V, 4V
- RdsOn(Max)@IdVgs: 3.7Ohm @ 80mA, 4V
- Vgs(th)(Max)@Id: -
- GateCharge(Qg)(Max)@Vgs: 1.58 nC @ 10 V
- Vgs(Max): ±10V
- InputCapacitance(Ciss)(Max)@Vds: 7 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): 150mW (Ta)
- OperatingTemperature: 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 3-SSFP
- 3LN01SS-TL-E onsemi (ON), MOSFET N-CH 30V 150MA SC81, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
3LN01SS-TL-E, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
