30A02CH-TL-E Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: SC-96
- Description: TRANS PNP 30V 0.7A CPH3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
30A02CH-TL-E Specifications:
- MfrPart.: 30A02CH-TL-E
- Mfr: onsemi
- Description: TRANS PNP 30V 0.7A CPH3
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- TransistorType: PNP
- Current-Collector(Ic)(Max): 700 mA
- Voltage-CollectorEmitterBreakdown(Max): 30 V
- VceSaturation(Max)@IbIc: 220mV @ 10mA, 200mA
- Current-CollectorCutoff(Max): 100nA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 200 @ 10mA, 2V
- Power-Max: 700 mW
- Frequency-Transition: 520MHz
- OperatingTemperature: 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: SC-96
- 30A02CH-TL-E onsemi (ON), TRANS PNP 30V 0.7A CPH3, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
30A02CH-TL-E, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
