2SK3747 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-3PML
- Description: MOSFET N-CH 1500V 2A TO3PML
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
2SK3747 Specifications:
- MfrPart.: 2SK3747
- Mfr: onsemi
- Description: MOSFET N-CH 1500V 2A TO3PML
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tray
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 1500 V
- Current-ContinuousDrain(Id)@25°C: 2A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 13Ohm @ 1A, 10V
- Vgs(th)(Max)@Id: -
- GateCharge(Qg)(Max)@Vgs: 37.5 nC @ 10 V
- Vgs(Max): ±35V
- InputCapacitance(Ciss)(Max)@Vds: 380 pF @ 30 V
- FETFeature: -
- PowerDissipation(Max): 3W (Ta), 50W (Tc)
- OperatingTemperature: 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-3PML
- 2SK3747 onsemi (ON), MOSFET N-CH 1500V 2A TO3PML, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
