2SK3703 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-220ML
- Description: MOSFET N-CH 60V 30A TO220ML
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
2SK3703 Specifications:
- MfrPart.: 2SK3703
- Mfr: onsemi
- Description: MOSFET N-CH 60V 30A TO220ML
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 60 V
- Current-ContinuousDrain(Id)@25°C: 30A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 4V, 10V
- RdsOn(Max)@IdVgs: 26mOhm @ 15A, 10V
- Vgs(th)(Max)@Id: -
- GateCharge(Qg)(Max)@Vgs: 40 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 1780 pF @ 20 V
- FETFeature: -
- PowerDissipation(Max): 2W (Ta), 25W (Tc)
- OperatingTemperature: 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-220ML
- 2SK3703 onsemi (ON), MOSFET N-CH 60V 30A TO220ML, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
