2SD1805F-TL-E Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- Description: TRANS NPN 20V 5A TPFA
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
2SD1805F-TL-E Specifications:
- MfrPart.: 2SD1805F-TL-E
- Mfr: onsemi
- Description: TRANS NPN 20V 5A TPFA
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- TransistorType: NPN
- Current-Collector(Ic)(Max): 5 A
- Voltage-CollectorEmitterBreakdown(Max): 20 V
- VceSaturation(Max)@IbIc: 500mV @ 60mA, 3A
- Current-CollectorCutoff(Max): 100nA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 160 @ 500mA, 2V
- Power-Max: 1 W
- Frequency-Transition: 120MHz
- OperatingTemperature: 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- 2SD1805F-TL-E onsemi (ON), TRANS NPN 20V 5A TPFA, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
2SD1805F-TL-E, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
