2SD1685G onsemi 20 V, 5 A, LOW VCE(SAT), NPN SIN
2SD1685G Images
2SD1685G Images
2SD1685G
  • Manufacturer: onsemi (ON)
  • Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-225AA, TO-126-3
  • Description: 20 V, 5 A, LOW VCE(SAT), NPN SIN
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
2SD1685G Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
2SD1685G Specifications:
  • MfrPart.: 2SD1685G
  • Mfr: onsemi
  • Description: 20 V, 5 A, LOW VCE(SAT), NPN SIN
  • Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
  • Package: Bulk
  • Series: -
  • PartStatus: Obsolete
  • TransistorType: NPN
  • Current-Collector(Ic)(Max): 5 A
  • Voltage-CollectorEmitterBreakdown(Max): 20 V
  • VceSaturation(Max)@IbIc: 500mV @ 60mA, 3A
  • Current-CollectorCutoff(Max): 100nA (ICBO)
  • DCCurrentGain(hFE)(Min)@IcVce: 280 @ 500mA, 2V
  • Power-Max: 1.5 W
  • Frequency-Transition: 120MHz
  • OperatingTemperature: 150°C (TJ)
  • MountingType: Through Hole
  • Package/Case: TO-225AA, TO-126-3
  • 2SD1685G onsemi (ON), 20 V, 5 A, LOW VCE(SAT), NPN SIN, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
