2SC3503FSTU Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-225AA, TO-126-3
- Description: TRANS NPN 300V 0.1A TO-126
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
2SC3503FSTU Specifications:
- MfrPart.: 2SC3503FSTU
- Mfr: onsemi
- Description: TRANS NPN 300V 0.1A TO-126
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- TransistorType: NPN
- Current-Collector(Ic)(Max): 100 mA
- Voltage-CollectorEmitterBreakdown(Max): 300 V
- VceSaturation(Max)@IbIc: 600mV @ 2mA, 20mA
- Current-CollectorCutoff(Max): 100nA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 160 @ 10mA, 10V
- Power-Max: 7 W
- Frequency-Transition: 150MHz
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-225AA, TO-126-3
- 2SC3503FSTU onsemi (ON), TRANS NPN 300V 0.1A TO-126, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
2SC3503FSTU, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
