2SB1143S Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-225AA, TO-126-3
- Description: TRANS PNP 50V 4A TO126ML
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
2SB1143S Specifications:
- MfrPart.: 2SB1143S
- Mfr: onsemi
- Description: TRANS PNP 50V 4A TO126ML
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Bag
- Series: -
- PartStatus: Obsolete
- TransistorType: PNP
- Current-Collector(Ic)(Max): 4 A
- Voltage-CollectorEmitterBreakdown(Max): 50 V
- VceSaturation(Max)@IbIc: 700mV @ 100mA, 2A
- Current-CollectorCutoff(Max): 1µA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 140 @ 100mA, 2V
- Power-Max: 1.5 W
- Frequency-Transition: 150MHz
- OperatingTemperature: 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-225AA, TO-126-3
- 2SB1143S onsemi (ON), TRANS PNP 50V 4A TO126ML, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
