2SA2222 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-220-3 Full Pack
- Description: TRANS PNP 50V 10A TO-220ML
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
2SA2222 Specifications:
- MfrPart.: 2SA2222
- Mfr: onsemi
- Description: TRANS PNP 50V 10A TO-220ML
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- TransistorType: PNP
- Current-Collector(Ic)(Max): 10 A
- Voltage-CollectorEmitterBreakdown(Max): 50 V
- VceSaturation(Max)@IbIc: 500mV @ 300mA, 6A
- Current-CollectorCutoff(Max): 10µA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 150 @ 270mA, 2V
- Power-Max: 2 W
- Frequency-Transition: 230MHz
- OperatingTemperature: 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3 Full Pack
- 2SA2222 onsemi (ON), TRANS PNP 50V 10A TO-220ML, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
2SA2222, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
