2SA1419S-TD-H Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-243AA
- Description: TRANS PNP 160V 1.5A PCP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
2SA1419S-TD-H Specifications:
- MfrPart.: 2SA1419S-TD-H
- Mfr: onsemi
- Description: TRANS PNP 160V 1.5A PCP
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- TransistorType: PNP
- Current-Collector(Ic)(Max): 1.5 A
- Voltage-CollectorEmitterBreakdown(Max): 160 V
- VceSaturation(Max)@IbIc: 500mV @ 50mA, 500mA
- Current-CollectorCutoff(Max): 1µA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 140 @ 100mA, 5V
- Power-Max: 500 mW
- Frequency-Transition: 120MHz
- OperatingTemperature: 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-243AA
- 2SA1419S-TD-H onsemi (ON), TRANS PNP 160V 1.5A PCP, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
2SA1419S-TD-H, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
