2N7002WST1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SC-70-3 (SOT323)
- Description: MOSFET N-CH 60V 0.115A SC70
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
2N7002WST1G Specifications:
- MfrPart.: 2N7002WST1G
- Mfr: onsemi
- Description: MOSFET N-CH 60V 0.115A SC70
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- FETType: -
- Technology: -
- DraintoSourceVoltage(Vdss): -
- Current-ContinuousDrain(Id)@25°C: 310mA (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: -
- Vgs(th)(Max)@Id: -
- GateCharge(Qg)(Max)@Vgs: -
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: -
- FETFeature: -
- PowerDissipation(Max): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: SC-70-3 (SOT323)
- 2N7002WST1G onsemi (ON), MOSFET N-CH 60V 0.115A SC70, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
2N7002WST1G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
