2N7002T Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SC-89-3
- Description: MOSFET N-CH 60V 115MA SOT-523F
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
2N7002T Specifications:
- MfrPart.: 2N7002T
- Mfr: onsemi
- Description: MOSFET N-CH 60V 115MA SOT-523F
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 60 V
- Current-ContinuousDrain(Id)@25°C: 115mA (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 5V, 10V
- RdsOn(Max)@IdVgs: 7.5Ohm @ 50mA, 5V
- Vgs(th)(Max)@Id: 2V @ 250µA
- GateCharge(Qg)(Max)@Vgs: -
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 50 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 200mW (Ta)
- OperatingTemperature: 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: SC-89-3
- 2N7002T onsemi (ON), MOSFET N-CH 60V 115MA SOT-523F, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
