2N7002ET3G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SOT-23-3 (TO-236)
- Description: MOSFET N-CH 60V 260MA SOT23-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
2N7002ET3G Specifications:
- MfrPart.: 2N7002ET3G
- Mfr: onsemi
- Description: MOSFET N-CH 60V 260MA SOT23-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 60 V
- Current-ContinuousDrain(Id)@25°C: 260mA (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 2.5Ohm @ 240mA, 10V
- Vgs(th)(Max)@Id: 2.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 0.81 nC @ 5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 26.7 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 300mW (Tj)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: SOT-23-3 (TO-236)
- 2N7002ET3G onsemi (ON), MOSFET N-CH 60V 260MA SOT23-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
