2N6509 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Thyristors - SCRs Package/Case: TO-220-3
- Description: SCR 800V 25A TO220AB
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
2N6509 Specifications:
- MfrPart.: 2N6509
- Mfr: onsemi
- Description: SCR 800V 25A TO220AB
- Product Category: Discrete Semiconductor Products~Thyristors - SCRs
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- Voltage-OffState: 800 V
- Voltage-GateTrigger(Vgt)(Max): 1.5 V
- Current-GateTrigger(Igt)(Max): 30 mA
- Voltage-OnState(Vtm)(Max): -
- Current-OnState(It(AV))(Max): 16 A
- Current-OnState(It(RMS))(Max): 25 A
- Current-Hold(Ih)(Max): 40 mA
- Current-OffState(Max): -
- Current-NonRepSurge5060Hz(Itsm): 250A @ 60Hz
- SCRType: Standard Recovery
- OperatingTemperature: -
- MountingType: Through Hole
- Package/Case: TO-220-3
- 2N6509 onsemi (ON), SCR 800V 25A TO220AB, Discrete Semiconductor Products~Thyristors - SCRs
