2N5682 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-205AD, TO-39-3 Metal Can
- Description: NPN 120V 1A 10W /2N5680 COMPLMT
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
2N5682 Specifications:
- MfrPart.: 2N5682
- Mfr: onsemi
- Description: NPN 120V 1A 10W /2N5680 COMPLMT
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- TransistorType: NPN
- Current-Collector(Ic)(Max): 1 A
- Voltage-CollectorEmitterBreakdown(Max): 120 V
- VceSaturation(Max)@IbIc: 1V @ 50mA, 500mA
- Current-CollectorCutoff(Max): 10µA
- DCCurrentGain(hFE)(Min)@IcVce: 40 @ 250mA, 2V
- Power-Max: 1 W
- Frequency-Transition: -
- OperatingTemperature: -
- MountingType: Through Hole
- Package/Case: TO-205AD, TO-39-3 Metal Can
- 2N5682 onsemi (ON), NPN 120V 1A 10W /2N5680 COMPLMT, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
2N5682, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
