2N5680 onsemi PNP 120V 1A 10W /2N5682 COMPLMT
2N5680 Images
2N5680 Images
2N5680
  • Manufacturer: onsemi (ON)
  • Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-205AD, TO-39-3 Metal Can
  • Description: PNP 120V 1A 10W /2N5682 COMPLMT
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
2N5680 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
2N5680 Specifications:
  • MfrPart.: 2N5680
  • Mfr: onsemi
  • Description: PNP 120V 1A 10W /2N5682 COMPLMT
  • Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
  • Package: Bulk
  • Series: -
  • PartStatus: Obsolete
  • TransistorType: PNP
  • Current-Collector(Ic)(Max): 1 A
  • Voltage-CollectorEmitterBreakdown(Max): 120 V
  • VceSaturation(Max)@IbIc: 1V @ 50mA, 500mA
  • Current-CollectorCutoff(Max): 10µA
  • DCCurrentGain(hFE)(Min)@IcVce: 40 @ 250mA, 2V
  • Power-Max: 1 W
  • Frequency-Transition: -
  • OperatingTemperature: -
  • MountingType: Through Hole
  • Package/Case: TO-205AD, TO-39-3 Metal Can
  • 2N5680 onsemi (ON), PNP 120V 1A 10W /2N5682 COMPLMT, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
