2N4402TF Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
- Description: TRANS PNP 40V 0.6A TO-92
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
2N4402TF Specifications:
- MfrPart.: 2N4402TF
- Mfr: onsemi
- Description: TRANS PNP 40V 0.6A TO-92
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- TransistorType: PNP
- Current-Collector(Ic)(Max): 600 mA
- Voltage-CollectorEmitterBreakdown(Max): 40 V
- VceSaturation(Max)@IbIc: 750mV @ 50mA, 500mA
- Current-CollectorCutoff(Max): -
- DCCurrentGain(hFE)(Min)@IcVce: 50 @ 150mA, 2V
- Power-Max: 625 mW
- Frequency-Transition: -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
- 2N4402TF onsemi (ON), TRANS PNP 40V 0.6A TO-92, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
2N4402TF, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
