1N4454 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: DO-204AH, DO-35, Axial
- Description: HIGH CONDUCTANCE ULTRA FAST DIOD
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
1N4454 Specifications:
- Manufacturer Product Number: 1N4454
- Mfr: Fairchild Semiconductor (Now part of ONsemi)
- Detailed Description: HIGH CONDUCTANCE ULTRA FAST DIOD
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
- Package: Bulk
- Series: -
- Part Status: Active
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 75 V
- Current - Average Rectified (Io): 200mA
- Voltage - Forward (Vf) (Max) @ If: 1 V @ 10 mA
- Speed: Small Signal =< 200mA (Io), Any Speed
- Reverse Recovery Time (trr): 4 ns
- Current - Reverse Leakage @ Vr: 100 nA @ 50 V
- Capacitance @ Vr, F: -
- Mounting Type: Through Hole
- Package / Case: DO-204AH, DO-35, Axial
- Operating Temperature - Junction: -65°C ~ 175°C
- 1N4454 onsemi (ON), HIGH CONDUCTANCE ULTRA FAST DIOD, Discrete Semiconductor Products~Diodes - Rectifiers - Single
