1N4149 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: DO-204AH, DO-35, Axial
- Description: DIODE GEN PURP 100V 500MA DO35
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
1N4149 Specifications:
- Manufacturer Product Number: 1N4149
- Mfr: onsemi
- Detailed Description: DIODE GEN PURP 100V 500MA DO35
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
- Package: Bulk
- Series: -
- Part Status: Active
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 100 V
- Current - Average Rectified (Io): 500mA
- Voltage - Forward (Vf) (Max) @ If: 1 V @ 10 mA
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 4 ns
- Current - Reverse Leakage @ Vr: 25 nA @ 20 V
- Capacitance @ Vr, F: 2pF @ 0V, 1MHz
- Mounting Type: Through Hole
- Package / Case: DO-204AH, DO-35, Axial
- Operating Temperature - Junction: 175°C (Max)
- 1N4149 onsemi (ON), DIODE GEN PURP 100V 500MA DO35, Discrete Semiconductor Products~Diodes - Rectifiers - Single
