15C01M-TL-E Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: SC-70, SOT-323
- Description: TRANS NPN 15V 700MA 3MCP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
15C01M-TL-E Specifications:
- MfrPart.: 15C01M-TL-E
- Mfr: onsemi
- Description: TRANS NPN 15V 700MA 3MCP
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Tape & Reel (TR),Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- TransistorType: NPN
- Current-Collector(Ic)(Max): 700 mA
- Voltage-CollectorEmitterBreakdown(Max): 15 V
- VceSaturation(Max)@IbIc: 300mV @ 10mA, 200mA
- Current-CollectorCutoff(Max): 100nA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 300 @ 10mA, 2V
- Power-Max: 300 mW
- Frequency-Transition: 330MHz
- OperatingTemperature: 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: SC-70, SOT-323
- 15C01M-TL-E onsemi (ON), TRANS NPN 15V 700MA 3MCP, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
